C10200 sheet
Our inventory consists of C10100, C10200, ETP C110000, and C12200. Each of these pure coppers is used for multiple applications, because of their excellent electrical and thermal conductivity, outstanding corrosion resistance, and ease of fabrication, together with good strength and fatigue resistance
Thickness : 0.3-150 MM
Length : ≤6000 MM
Width : ≤3000 MM
MOQ : 1MT
Properties
chemical Composition
|
Alloy |
Chemical Composition (％) |
||||||||||||
|
C10200 |
Cu+Ag(MIN) |
P |
Ag |
Bi |
Sb |
As |
Fe |
Ni |
Pb |
Sn |
S |
Zn |
o |
|
99.97 |
0.002 |
— |
0.001 |
0.002 |
0.002 |
0.004 |
0.002 |
0.003 |
0.002 |
0.004 |
0.003 |
0.002 |
|
|
牌号 |
process |
size（mm） |
||
|
Thickness(mm) |
Width(mm) |
Length(mm) |
||
|
C10200 |
Hot rolling |
4～8 |
600-2000 |
≤5000 |
|
＞8～60 |
200-3000 |
≤6000 |
||
|
＞60～150 |
200-3000 |
≤6000 |
||
|
Cold rolling |
0.3～0.5 |
≤600 |
≤2000 |
|
|
＞0.5～3.0 |
≤1020 |
≤3000 |
||
|
>3.0-1.2 |
≤3000 |
≤6000 |
||
Mechanical Properties
|
Alloy |
Temper |
Thickness(mm) |
Rm/OViran2) Tensile Strength |
A11.3/% Elongtion |
Hardness(Hv) |
|
C10200 |
R |
4-14 |
Rm≥195Mpa |
A11.3≥30% |
- |
|
. 14 |
- |
- |
- |
||
|
M |
>0.5 |
Rm≥205Mpa |
A11.3≥30% |
≤70 |
|
|
Y4 |
Rm=215～275Mpa |
A11.3≥25% |
60-90 |
||
|
Y2 |
Rm=245～345Mpa |
A11.3≥8% |
80-110 |
||
|
Y |
Rm≥295～380Mpa |
- |
90-120 |
||
|
T |
Rm≥350Mpa |
- |
≥110 |
Features
>High electrical conductivity and durability
>High precision
>Narrow size tolerances
>Low-fat, smooth surface
>Concentrated materials composition
>High dimensional stability
>Mechannical and physical properties can be controlled
>Wide range of sizes and almost zero maintenance
>Excellent malleability, can beforged the broadest,thinnest and longest
> Good machinability
Thick plate/sheet
Thin plate/sheet
Typical Uses
electronic and comunication,Electronic and electrical industry,General hardware,Mechanical manufacturing,Household appliances,Automobile and new energy,Transportation,Metallurgical and chemical industry
