C11000 Strip

C11000 Strip

Our inventory consists of C10100, C10200, ETP C11000, and C12200. Each of these pure coppers is used for multiple applications, because of their excellent electrical and thermal conductivity, outstanding corrosion resistance, and ease of fabrication, together with good strength and fatigue resistance

Thickness : >0.15-3.0 MM

Width : ≤1000 MM

MOQ : 1MT

Properties



Alloy

product



Temper

size(mm)

Thickness

width

C11000

strip

Y、Y2、

Y4、M

>0.15-0.5

≤600

>0.5-3.0

≤1000

chemical Composition

 Alloy

 Chemical Composition

Cu

Pb

Fe

Zn

C11000

≥99.90

-

-

-



Mechanical Properties



Alloy

Temper

Thickness

Rm/OViran2) Tensile Strength

au.3/% Elongtion

 Hardness(HR)



C11000

M

≥0.2

Rm≥205Mpa

A11.3≥30%

70

Y4

Rm=215~275Mpa

A11.3≥25%

 60-90

Y2

Rm=245~345Mpa

A11.3≥8%

 80-110

Y

Rm≥295~380Mpa



60~8490-120

T

Rm≥350Mpa



 110





Features

>High electrical conductivity and durability

>High precision and low cost

>Narrow size tolerances

>Low-fat, smooth surface

>Concentrated materials composition

>High dimensional stability

>Mechannical and physical properties can be controlled

>Wide range of sizes and almost zero maintenance

>Excellent malleability, can beforged the broadest,thinnest and longest



Typical Uses

electronic and comunication,Architectural decoration,Electronic and electrical industry,General hardware,Mechanical manufacturing,Household appliances,Automobile and new energy,Transportation,Metallurgical and chemical industry

Please contact one of our knowledgeable sales staff to help you with your Copper needs.

Request a Quote
