C4640 sheet
Naval Brass is used extensively in marine construction due to its high corrosion resistance to seawater It is known for its good strength, good rigidity/hardness and resistance to wear, fatigue, galling and stress cracking. Also recognized for superior tensile strength, higher yield strength, good elongation, excellent thermal conductivity, good capacity for being cold worked, excellent capacity for being hot formed and excellent soldering and brazing
Thickness : 3.0-60 MM
Length : ≤6000 MM
Width : ≤3000 MM
Properties
|
Alloy |
process |
Size（mm） |
||
|
Thickness |
Width |
Length |
||
|
C4640 |
Hot rolling |
4.0～8 |
600～2000 |
≤4000 |
|
＞8～60 |
600～3000 |
≤6000 |
||
|
Cold rolling |
|
|||
|
＞3.0～10 |
≤2500 |
≤4000 |
||
chemical Composition
|
合金牌号 Alloy |
化学成分％ Chemical Composition |
||||
|
Cu |
Sn |
Pb |
Fe |
Zn |
|
|
C4640 |
59.0-62.0 |
0.5-1.0 |
≤0.20 |
≤0.10 |
余量Rem |
Mechanical Properties
|
Alloy |
Temper |
Tensile Strength |
Elongation% |
Hardness(HR) |
|
|
F |
≥340 |
≥20 |
- |
|
C4640 |
O |
≥295 |
≥35 |
- |
|
|
H/2 |
350-400 |
≥15 |
- |
|
|
H |
≥390 |
≥5 |
- |
Features
1) Good wear resistance
2) Excellent corrosion resistance
3) High intensity
4) Hot Forging performance
5) Good cutting performance
6) Self-lubricating performance
Thin plate/sheet
Thick plate/sheet
Typical Uses
Naval Brass presents a high corrosion resistance to seawater, making it a top candidate for industrial and marine atmosphere jobs. It offers excellent properties for being hot worked, while also keeping the ability to be moderately cold worked.
